3-WAY BALL VALVE ‘T’ PORT Bottom Entry Chrome Plated Brass
SKU BVTPBE
AU$58.40
In stock
1
Product Details
Valves & Nozzles | 3-WAY BALL VALVE ‘T’ PORT Bottom Entry
Add this 3-Way Ball Valve with "T" Port Bottom Entry to your Valves and Nozzles. It is Brass Nickel Plated with its ball made from brass chrome plated material. Read on.
Bottom Entry Part No. | Description |
BVTP10BE | 10mm 3-WAY BALL VALVE ‘T’ PORT |
BVTP12BE | 12mm 3-WAY BALL VALVE ‘T’ PORT |
BVTP20BE | 20mm 3-WAY BALL VALVE ‘T’ PORT |
BVTP25BE | 25mm 3-WAY BALL VALVE ‘T’ PORT |
BVTP32BE | 32mm 3-WAY BALL VALVE ‘T’ PORT |
BVTP40BE | 40mm 3-WAY BALL VALVE ‘T’ PORT |
BVTP50BE | 50mm 3-WAY BALL VALVE ‘T’ PORT |
Specifications
Part | Material |
Body | Brass Nickel Plated |
Seat | P.T.F.E |
Ball | Brass Chrome Plated |
Stem | Brass |
Handle | Stainless Steel |
Nut | Stainless Steel |
Max Temperature | 150 DegC |
Cold Working pressure | 2500kpa |
